Algunos modelos compatibles:

U6-lite

U6+
UAP-AC-LITE (version 802.3af)
UAP-AC-LR (version 802.3af)
UAP-AC-PRO
UAP-NANOHD
Otros Consultar

Compatible con dispositivos 802.3af!

Output Voltage: 48VDC @ 0.32A
LAN Activity Indicator: No
Gigabit LAN Port: Yes
Remote Reset Capability: Yes
Reset Button: No
Rated Voltage: 100-240VAC @ 50/60Hz
Input Current: 500mA @ 90VAC
Inrush Current :<100A Peak @ 25°C
Efficiency: 0.8425
Output Ripple: 200mV p-p
Switching Frequency: 65 kHz
Line Regulation ≤ 3%
Load Regulation ≤ 5%
2-Pair Powering Pins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering –
Operating Temperature: 0 to 40° C
Storage Temperature: -30 to 70°C
Operating Humidity: 5 to 90% Noncondensing
Data IN / POE: RJ45 Shielded Socket
Surge Protection: Difference and Common Mode
Clamping Protection: 11V Data, 60V Power
Max. Surge Discharge: 1500A (8/20 μs) Power
Peak Pulse Current: 36A (10/1000 μs) Data
Shunt Capacitance: <5 pF data
Response Time: <1 ns
Certifications CE, FCC, IC, UL
